Review of Point Grey Camera for Microscopy

by Sam Lord

(originally posted here: http://blog.everydayscientist.com/?p=3550)

I bought a $500 camera from Point Grey that has the Sony IMX249 chip. It is a fairly large field of view with intermediate sized pixels (5.86 um), so it has a great dynamic range. The great thing is that it has low dark/read noise of 7-14 electrons per frame and a very high quantum efficiency of 80%. At it runs at up to 40 fps!

While this camera can't fully compete with scientific CMOS cameras like the Andor Zyla or Hamamatsu Flash4 (and definitely not with the Photometrics Prime95B), because these scientific cameras do a better job cooling (reducing dark counts) and on-chip correction of dead pixels or other pixel-to-pixel variability. But I wondered if this Point Grey camera could be a very cheap replacement for our old interline CCD (a Hamamatsu Orca-ER model C4742-80-12AG).

Recently, Nico wrote a Micro-Manager device adapter for USB3 Point Grey cameras, so I quickly bought the Blackfly BFLY-U3-23S6M-C and was happy to get beautiful images! The picture on the bottom is from the Point Grey and the one on the top is from the old interline camera. At the same exposure time, the images were very similar. And the Point Grey camera could run 4x faster if necessary. In addition, the Point Grey outputs 16-bit-images with much higher dynamic range than the old 12-bit interline CCD. I misread the specs: the video output is 16 bit, but the A/D converter is still only 12 bit.

So I plan to replace the interline camera with this Point Grey camera for day-to-day microscopy. I'll let you know if we run into any problems in the future.

Also, Kurt tested a different Point Grey camera with great results.

UPDATE:

Here are two more images, zoomed in and cropped. Top is Hamamatsu Orca-ER and bottom is the Point Grey Blackfly camera:

These were the same exposure time (200 ms) and the same magnification. I've decided to replace the Hamamatsu with the Point Grey camera.

Review of Elveflow Microfluidics Controller

by Johnny Rodriguez

We recently bought the OB1 microfluidic controller with the MFS2 flow sensors. In contrast to syringe pumps, pressurized control systems allow for very responsive, pulseless flow for a wide range of flow rates; this makes it ideal for our single molecule microscopy experiments.

The included instructions made assembly of the device a breeze. However, we initially were not able to create pulseless flow. It turns out that if the reservoir, flow sensors, and microfluidic chambers were not at the same height, pulseless flow was not attainable.

Channel flow and channel switching worked as advertised. The flow was very stable and channel switching happened within a second. If pulses were needed, the device had built-in features that allow the user to create custom pulses. One disadvantage of the system was that liquid would still flow when the channel flow was set to 0. This hydrostatic pressure flow was very slow, but it could ruin an experiment. This problem could be solved with the addition of valves. (The manufacturer also suggested we could increase the hydrostatic resistance of your setup in order to lower the influence of hydrostatic pressure and thus the residual flow.)

Overall, this is a great device for anyone seeking pulseless flow and rapid responsiveness. Elvesys has been great in responding to questions and we've enjoyed working with them.

Review of Photometrics Prime95B CMOS Camera

by Sam Lord

(originally posted here: http://blog.everydayscientist.com/?p=3471)

Photometrics has released the Prime 95B, the first scientific CMOS camera with a back-thinned sensor. This means that the sensor is significantly more sensitive than the front-illuminated versions of other CMOS scientific cameras. So the Prime 95B has a 95% quantum efficiency, whereas other scientific CMOS cameras have 60-70% QE; the newest version of competing CMOS cameras tout 80%+ QE. Back-thinning really helped CCD technology (EMCCDs are back-thinned, for example), but back-thinning CMOS sensors has been more challenging, for some technical reasons that I don't know.

I demoed the Prime 95B when it was in the Nikon Imaging Center (Kurt wrote up details here). The CMOS camera was installed on a spinning disk confocal along with a 1024x1024 pixel EMCCD. The Prime 95B has 11 um pixels, slightly smaller than the 13 um of the EMCCD's pixels; this results in a higher spatial sampling rate and thus lower sensitivity for the CMOS, because the photons are spread across more pixels. This can be simply corrected by using a different lens, but we didn't do that here. So it provided an unlevel playing field, favoring the EMCCD.

emccd vs prime bead

Despite that, the Prime 95B matched or outperformed the EMCCD in all the tests we did. The above image compares the EMCCD (left) with the Prime 95B (right) imaging a 100 um Tetraspeck bead. Below, I compare them imaging a fixed test sample at very low light levels.

emccd prime

The comparisons I made were mainly qualitative. By eye, I was not able to find conditions were the EMCCD outperformed the Prime 95B. That's saying a lot, especially because the Prime 95B costs approximately half as much! For single-molecule imaging, the EMCCD might still be the king (see Kurt's curve), but I didn't have time to perform those detailed or quantitative tests. But for all other imaging and spinning disk confocal, I'd rather have the Prime 95B. No more deciding the optimal EM gain settings and the large dynamic range of the CMOS make it a real winner!

Review of NanoLive Microscope

by Sam Lord

(originally posted here: http://blog.everydayscientist.com/?p=3451)

We got a chance to try out a cool new label-free microscope from NanoLive: the 3D Cell Explorer. It works on a holographic tomography, by rotating a laser beam around the top of the sample and records many transmitted-light images. It then uses software to reconstruct the image with phase and even 3D information. The small index differences of different organelles or regions of the cell results in different retardation of the phase of the transmitted light; in the reconstruction, these areas can be false-colored to give beautiful renderings of cells ... all without fluorescent labeling.

nanolive

nanolive2

We used the Nanolive to watch Naegleria amoeba crawling across a glass surface. These cells move orders of magnitude faster than fibroblasts (20 um/min), so imaging their movement is a serious challenge for many high-resolution microscopes.

The above video is false-colored for different index ranges. It is super cool to see the pseudopods in 3D, and possibly even distinguish the plasma membrane from the actin cortex. The demo went well and it took only about 15 min to take the microscope out of the box and start imaging.

When we demoed the beta version a year or so ago, and it had trouble imaging crawling amoebae: the background subtraction was manual and flaky and the frame rate was too slow. But Nanolive let us try it again after the actual release of the product and things works way better. The background subtraction is now automated and robust, and the frame rate was high enough to watch these fast crawling cells.

I think that this microscope would be a great choice for researchers studying organisms that are not genetically tractable or otherwise cannot be fluorescently labeled. Or for anyone studying organelles that show up with a different index (Naegleria ended up having relatively low-contrast organelles compared to adherent mammalian cells, for instance.)

Pro:

  • affordable (about the cost of an EMCCD camera)
  • label-free
  • low intensity (no phototoxicity or photobleaching)
  • simple and user-friendly: easier that setting up DIC in Koehler illumination 🙂
  • small footprint and easy setup
  • software is free
  • potential for beautiful and amazing data

Con:

  • not versatile: it does one thing (but does that one thing well)
  • limited to samples with wide top, like a 35 mm dish (not 96-well plates), because the laser beam comes in at an angle
  • 3D information on top and bottom of cells is less impressive

Go check it out!

Home-Built Coverslip Drier/Spinner

By Sam Lord

(originally posted here: http://blog.everydayscientist.com/?p=3349)

We wanted some coverslip spinners to dry coverslips after washing and rinsing. It's way faster than blowing them with air. Nico kindly gave me his 3D design file for the coverslip holder, and I modified the box design from here.

Here's a parts list (Digikey part numbers unless otherwise noted):

2015-04-03 11.42.00

And here's the finished product.

March 5, 2015

Congrats to Brittany Belin, who will start a postdoc Dianne Newman's lab at Caltech in April!

REVIEW: LED Illumination

By Sam Lord

(originally posted here: http://blog.everydayscientist.com/?p=3300)

LED illumination is awesome for epifluorescence. No mechanical shutters, changing mercury lamps every 200 hours, no hot lamphouses, no worries about letting it cool down before turning the lamp back on, less wasted electricity, immediately ready to use after turning it on, etc.

We have a Lumencor SpectraX on our Nikon TE2000 scope and we love it. It contains multiple LED that are independently triggerable. For high-speed imaging, we bought one new Chroma quad-band dichroic and emission filter set, as well as 4 separate single-band emission filters for our emission filter wheel (although this latter set is not absolutely necessary).

The amazing thing is to be able to run color sequences at the frame rate of the camera (because the SpectraX accepts TTL triggering of each line independently). It is beautiful to see the rainbow of light flashing out of the scope at 20+ frames per second!

https://micro-manager.org/wiki/Hardware-based_synchronization

We use a ESio TTL* box controlled by Micro-Manager and it works great. But you could use an Arduino and some simple wiring using a DE15 breakout board to accomplish the same thing for cheaper.

We haven't run into any issues with brightness: the SpectraX is bright enough for all our cell imaging experiments. Typically, we run it at 20% power. That said, I'm aware that the very bright peaks in an arc lamp spectrum (e.g. UV, 435, 546) aren't there in the LED spectra. So for FRAP or something, you may not be able to bleach as fast.

And, of course, a fancy illuminator like the Spectra X is not cheap. But for run-of-the-mill epi imaging, white-light sources like the Lumencor Sola might be a good option. Another downside is that the fans on the Spectra X are audible, but not annoying. Despite that minor issue and the cost, I highly recommend LED illumination (and the Spectra X, specifically).

I recommend you demo a few LED sources from a few companies (e.g. ScopeLED, Lumencor, Sutter, etc.) and make sure it will fit your needs.

____________

* Make sure your camera supports TTL triggering of an external shutter.

REVIEW: GATTAquant Fluorescence Standards Review

By Sam

(originally posted here: http://blog.everydayscientist.com/?p=3314)

Jürgen Schmied from GATTAquant came by the other day and let me play around with some of their cool DNA origami fluorescence standards.

The PAINT sample was really cool. It has short oligos on the DNA origami and complementary strands labeled with dyes in solution. The binding/bleaching kinetics are such that each hotspot blinks many times during an acquisition. After a quick 10,000 frame acquisition over 3 min, we collected a dataset that we could easily get a super-resolution image. We used ThunderSTORM to fit the data and correct for drift. But without any other corrections, we could easily resolve the three PAINT hotspots on each DNA origami:

Screen Shot 2015-02-13 at 5.12.44 PM

But my favorite sample was actually the confocal test slide. It had two sets of dyes about 350 nm apart permanently labeled on each DNA origami.

Screen Shot 2015-02-13 at 5.13.05 PM

This let me test the resolution and image quality using different configurations on our Diskovery confocal/TIRF system.

Screen Shot 2015-02-13 at 5.13.21 PM

Each spot contained only about 4-8 dyes. So it was a much greater challenge to our microscope than TetraSpeck beads.

Screen Shot 2015-02-13 at 5.12.55 PM

I highly recommend GATTAquant test samples. Very fun.

UPDATE: Jürgen ran my data though GATTAquant's analysis software and sent me the results below.

export3_image

export3_FWHM histogram

export3_Distance histogram

REVIEW: Harrick Plasma Cleaner

By Sam

(originally published here: http://blog.everydayscientist.com/?p=3296)

I had previously made my own plasma cleaner using a pump and an old microwave. While my homemade version technically worked, it was complicated to use, unwieldily, and inconsistent in performance. In fact, at least one test made my glass coverslips dirtier.

So we purchased a Harrick plasma cleaner. I've used these in the past for preparing coverslips for single-molecule imaging as well treating coverslips before forming supported lipid bilayers on the glass. I've always found plasma treatment to be simpler and more consistent that chemical methods such as piranha.

2014-12-18 11.45.47

You can see a lot of single-molecule level fluorescent impurities on the glass surface before cleaning (these are a few frames stitched together):

not cleaned

And after 4 minutes of plasma treatment (with air as the process gas) it was so clean that I had trouble finding the correct focal plane:

plasma cleaned for 4 min

People are also using this plasma cleaner to treat material for PDMS bonding to glass. They say it's been working very consistently.

So I highly recommend plasma cleaning. It takes literally a few minutes and there's no hazardous waste to dispose of. The only real drawback is the price: a new cleaner plus pump costs several thousand dollars. In the long run, if we can get consistent science and no haz waste disposal costs, that price will be worth it. (We also split the cost with several other labs on our floor.)

I've also heard good things about ozone treatment. Anyone have any comments about ozone vs plasma?

Pro:

  • Very easy to use
  • Fast (<5 min) cleaning
  • Effective
  • Consistent
  • Updated models of Harrick cleaners have a nice hinged door

Con:

  • Expensive
  • Using process gases other than simply air (such as argon) is slightly more complicated, because you'll need a tank and tubing; oxygen plasma cleaning requires a more expensive pump

REVIEW: Coherent Obis Galaxy laser combiner

By Sam

(originally published here: http://blog.everydayscientist.com/?p=3174)

We recently purchased new lasers for our TIRF scope. I wanted the flexibility and low cost of a home-built laser combiner, but also I wanted the ease and stability of a turn-key laser box. I stumbled upon Coherent’s Obis Galaxy combiner, which uses up to 8 fiber pigtailed lasers and combines the emission into one output fiber. What I really love about the idea is that you can add lasers in the future as your experimental needs grow. (Or your budget does.)

The other aspect I love is that it’s just plug and play! If I were on vacation when a new laser arrived, anyone in lab should be able to add it to this system.

2014-07-03-15.22.03

We also purchased the LaserBox, which supplies power, cooling, and separate digital/analog control to 5 lasers.

2014-07-03-15.07.33

The new system just sits on the shelf. It's tiny:

2014-07-03-15.45.57

Here it is in action. The lasers were being triggered and sequenced by the camera and an ESio board, so they were running so fast I had to jiggle my iPhone in order to see the different colors.

One problem that I have faced is that the throughput is lower than spec (should be 60%+, and it's down at 40%). Coherent is going to repair or replace the unit. And fortunately, we're only running the lasers at 10% or less for most experiments currently, so there's no rush to get the throughput higher!

If you're ever in Genentech Hall UCSF and want a quick demo, drop me a line!

Pro:

  • Flexibility to add laser lines or upgrade lasers in the future at no additional cost (besides the pigtailed laser itself) and no downtime
  • Super easy installation
  • Cheaper than many of the other turn-key boxes
  • No aligning or maintenance needed
  • Each laser can be separately triggered and modulated (digital and/or analog)
  • Replaceable output fiber if it gets damaged (although it might not be as high-throughput as the original fiber)
  • Small and light, so it's easy to find a place for it in any lab

Con:

  • No dual-fiber output option
  • Two boxes and some fibers going between the two makes it a little less portable than some of the other small boxes
  • No space to add optics (e.g. polarizers) in launch
  • Fans for LaserBox are not silent
  • Power and emission LEDs are too bright
  • NA of Coherent fiber is slightly smaller than that of Nikon TIRF illuminator expects, but the effect is barely observable (Coherent is working on a second fiber option that would even better match the TIRF illuminator)

Bottom line: I'd definitely recommend the Galaxy if you're primary goals are color flexibility and simplicity. If you want more turn-key (and probably stability, but I can't speak to that yet), there are other boxes to consider: Spectral ILE, Vortran Versa-Lase, Toptica MLE, and so on. Also, if you needed two (or more) fiber output, the Galaxy doesn't have that option.

~~~

Edit 11/10/2014: I've found one issue. The NA of the Coherent fiber is smaller (0.055) than the standard Oz Optics fiber that Nikon uses for the TIRF launch (0.11). That means that the illumination is more compact at the sample. Because the beam is Gaussian shaped, that means that the illumination is less flat (i.e. very bright in the center and darker on the edges). I'm going to try a solution using a second fiber with the correct 0.11 NA and an Oz Optics AA-300 lens style universal connector. I'll update if this works...

Edit 3/5/15: So it turns out that the NA difference isn't that huge. Most of the discrepancy is just a difference in the way the two manufacturers report the NA. Not only that, but in practice the NA difference makes a tiny change in the illumination area in TIRF. I wouldn't let the different NA stop you from considering this product. Also, Coherent is working on second fiber option that would even better match the TIRF illuminator. Contact Coherent to see if they can make one with a 0.074 NA (1/e2) output to match the NA of the Oz Optics (Corning) fibers that the Nikon illuminator expects.

Edit 7/30/15: The LaserBox has a 50 Ohm impedance for the digital modulation (2 kOhm for analog), because it needs to be able to driven up to 150 MHz, according to Coherent. This makes controlling the digital TTL with an Arduino a challenge, because the Uno is rated for 40 mA max. The ESio board (and maybe the TriggerScope?) can handle the higher currents. That said, the Arduino Uno seems to handle the higher current draw even though it's not spec'ed to: I have a lot of anecdotal evidence that you can use an Arduino to control Obis lasers. (Maybe not 2 lines simultaneously?) Contact Coherent before you order to see if they can send one with higher impedance for the TTLs.
